GoldenRod 496 Water Block Fuel Tank Filter
Need assistance?
We are happy to answer any questions you may have.
Contact usOr call us on 01342 713743
The GoldenRod 496 Fuel Tank Filter is the water block filter for diesel from the leading filtration brand in the agricultural market. Whilst used within many industries for filtering water out of the fuel in a diesel storage tank, thanks to being suitable for gravy fed installations as well as compatible pumping systems, GoldenRod fuel filters are widely recognised amongst the farming community.
The 496 fuel tank filters benefit from a paper cartridge element inside a clear bowl with a drain point, allowing for the viewing and subsequent removal of any free water that have been removed from the storage tank contents. The element works by using water-absorbing polymers, which trap up to approximately half a cup of water before needing to be replaced.
All GoldenRod filter components including the replacement GoldenRod 496-5 element are available individually as replacements (see accessories table).
Features of the GoldenRod Water Block Filter for Storage Tanks:
- 17 micron water block filter
- Paper filter element
- Maximum flow rate of 95 Ltrs Per Min
- For gravity & pump systems
- 1” F BSP Inlet/Outlet
- 1 1/8"-12 M UNF Filter Thread
- Heavy duty zinc die-cast head with excellent seal
- Suitable for diesel, bio up to B20, petrol
- Includes 1 x filter head and 1 x filter element
Available Options
CTJ1818
Inc. VAT: £27.12
Filter Head
Goldenrod 496 Fuel Filter Complete
Inc. VAT: £86.14
17 Micron Particle and Water Filter Paper Filter Application - Gravity/Pump Max Flow Rate (lpm) - 95 Pressure (bar) - 10 Inlet/Outlet - 1" F BSP Filter Thread - 1 1/8"-12 M UNF Diesel, bio up to B20, petrol
GoldenRod 496-5 Element Only
Inc. VAT: £30.84
17 Micron Particle and Water Filter Max Flow Rate (lpm) - 95 Pressure (bar) - 10 For gravity and pump systems
GoldenRod Fuel Filter Housing 495-4
Inc. VAT: £34.82
For use with GoldenRod filters
GoldenRod Wrench 491
Inc. VAT: £16.03
For use with GoldenRod filters
| Code | Name | Description | Price | Buy |
|---|---|---|---|---|
| CTJ1818 | CTJ1818 | Filter Head |
£22.60
Inc. VAT: £27.12 |
|
| CTJ1809 | Goldenrod 496 Fuel Filter Complete | 17 Micron Particle and Water Filter Paper Filter Application - Gravity/Pump Max Flow Rate (lpm) - 95 Pressure (bar) - 10 Inlet/Outlet - 1" F BSP Filter Thread - 1 1/8"-12 M UNF Diesel, bio up to B20, petrol |
£71.78
Inc. VAT: £86.14 |
|
| CTJ1810 | GoldenRod 496-5 Element Only | 17 Micron Particle and Water Filter Max Flow Rate (lpm) - 95 Pressure (bar) - 10 For gravity and pump systems |
£25.70
Inc. VAT: £30.84 |
|
| CTJ1802 | GoldenRod Fuel Filter Housing 495-4 | For use with GoldenRod filters |
£29.02
Inc. VAT: £34.82 |
|
| CTJ1813 | GoldenRod Wrench 491 | For use with GoldenRod filters |
£13.36
Inc. VAT: £16.03 |
