Exhaust Insulation Wrap - Natural
Code: SOOTFILTER Nrmm Cartridge Series Soot Filters

NRMM Cartridge Series Soot Filters

The Cartridge Series Particulate Filter is designed for use with diesel vehicles and other diesel-powered devices. There are 4 models, up to 35 kW, up to 85 kW, up to 150 kW and for stationary and mobile applications up to 300 kW engines.

The rugged casing is made of Werkst. No. 1.4301 stainless steel and tool-grade AlMgSi1 aluminum. The casing cover is fastened with a quick-action clasp, allowing fast and easy replacement of filter cartridges.

The Cartridge Series Particulate Filter is not a substitute for a muffler; however it does result in improved acoustic damping.

As standard, each system is supplied with a back pressure monitor offering an audiable and visual alarm.

Specifications

  • Listed on the NRMM Register as Certified by the Energy Saving Trust
  • S****ervice Life of >400 hours, depending on the maintenance condition of the engine
  • Efficiency of >98% reduction of Diesel Particulate Emissions
  • Maximum Continuous Operating Temperatue of 350°C
  • Short Term Temperature Spikes (upto 30mins) of 400°C
  • Included in Delivery: Particulate Filter including Filter Cartridge, Backpressure Monitor, Ermeto Tube, 2x Retaining Clips, Silicon Tube for condensation draining, Connecting Flange with Gasket and Screws

Downloads

41005 Cartridge Series Soot Filters 2pp.pdf IOM Cartridge Series Soot Filters.pdf
